ARTSEN
ARTSEN
Features
- Full digital and intelligent control; superbly high frequency of 100KHz; zero delay in sampling circuit to gain precise reaction to the status of the metal droplet.
- Unique desig n of power releasing allowing welding current to be lowered as fast as 10,000A / millisecond. The current force has the lowest impact on the melt at the moment of metal transfer. Applying worm gear motor of high torque and low inertia, and the highly precise code wheel of 120 lines and the HF motor control system. Start-up, braking and withdrawal at millisecond level are reached. Withdrawal at both the arc ignition and ending stage are controlled precisely. Together with the welding parameter control, optimum arc ignition and crater performance are gained.
- Far-end sampling and compensation of both the positive and negative output. A clear and precise judgement of the transfer status, and an accurate control as a result, can be made even when output cable reaches 30m.
- A stable and comprehensive hardware platform of high speed. The open software system makes it possible to expand process control program for different welding conditions and co ect expert database, meeting continuously updating process demands from customers.
The Brand-new Job Mode for Flexible Collocation of Welding Process
Double Pulse? Dual DC? Pulse DC? All up to you!
- Independent config ura tion of duration time, control mode, control parameters, collocation parameters, descending characteristics.
- Two processes to be collocated under the same JOB. Complicated job switch commands is no longer needed. Switching between processes can be completed thru just one press on the torch.
- Smooth transition between different jobs. Distortion of welding arc and spatter during transition can be largely reduced. Characteristics of transition can be configured in each job.
| MODEL | Artsen Plus 500D/P/Q | Artsen Plus 400D/P/Q | Artsen Plus 350D/P/Q | |
| Robotics | Artsen Plus 500D/P/Q R | Artsen Plus 400D/P/Q R | Artsen Plus 350D/P/Q R | |
| Control Mode | Full Digital Control | |||
| Rated Input Voltage | Ac3PH 380V+/-25%(3PH 285V~3PH 475V) | AC 3PH 380V+/-25%(3PH 285V~3PH 475V)AC 3PH 220V +/-15% (3PH 187V~3PH 254V) | ||
| Input Frequency | 45 ~65 HZ | |||
| Rated Input Power | 24 KVA | 22.3 KVA | 16.8KVA | |
| Power Factor | 0.93 | |||
| Efficiency | 87% | |||
| Rated OCV | 85V | |||
| Rated Output Current | 30 ~ 500 A | 30 ~ 400 A | 30 ~ 350 A | |
| Rated Output Voltage | 12 ~ 45. V (Precision at 0.1V) | |||
| Duty Cycle | 500A/39V 60% @ 40°C 387A/33.5V 100% @40°C | 400A/34V 100% @ 40°C | 350A/33.5V 60% @40°C | |
| Applicable Material | D: Carbon Steel P: Carbon Steel & Carbon Steel / Stainless/Aluminum AlloyS |
|||
| Welding Process | D: MIG / MAG /CO2; Low-spatter; P: MIG / MAG / CO2;Low-spatter; Short-arc Pulse Q: MIG / MAG / CO9;Low-spatter; Short-arc Pulse |
|||
| Wire Diameter | @0.8/0.9/1.0/1.2/1.6 mm | |||
| Welding Operation Mode | 2T / AT / Special 4T / SpotWelding / Leaping Welding | |||
| Inductance Scope (Soft / Strong Arc) | -7~+7 | |||
| Push-pull Torch Function (1) | Yes | |||
| Communication with-Robot Controller | Analog;DeviceNet;CAN Open;MEGMEET CAN;EtherNET/IP(2) | |||
| Digital Meter on Wire-feeder | Yes | |||
| Cooling Mode | Air Cool; WaterCool (Optional) | |||
| Electromagnetic Compatibility | IEC60974:10EMS | |||
| Insulation Grade | H | |||
| Ingress Protection | IP23S | |||
| Protection Against Lightening | Class D (6000V/3000A) | |||
| Working Temprature &Humidity | -39°C ~ +50°C;Humidity ≤ 95%; | |||
| Dimension (L / W / H) | 620 x 300x 480 mm | |||
| Gross Weight | 52KG | |||
| RatedPower | 260W | |||
| Rated Voltage | AC400V | |||
| Volume of Cooling Water | 10L | |||
| Flow of Cooling Water | 3.5L/ min | |||
| Max Pump Head | 30m | |||
| Flow Alarm | Yes | |||
